Using Franka

Setting Up

Visit https://de3-rob1-chess.readthedocs.io to see how franka was setted up.

This site was used to install the live kernel, libfranka and franka_ros.

Connecting to FRANKA

Using Wifi: The FRANKA connection should be automatically done.

Using Ethernet Cable: Create a wireless network using the IP address of the robot and IP address of the computer and use them to connect to the robot. After that you can connect to the web interface.

Using the Web Interface:

To connect to the web interface go to https://robot.franka.de.

Without using the lanline to connect FRANKA and the laptop, the web interface can be accessed through the IP address (https://192.168.0.88) to unlock the brakes before starting.

The login is:

• Username: robin
• Password: deniro

Connection between Franka and the computer terminal can be made done using Wifi or an ethernet cable.

Controlling Franka

FRANKA can be controlled using the libfranka library, which is only accessible using the C++ language. Petar and Fabian have made some libfranka functions accessible by Python and the Chess team has made a Python library for FRANKA.

Credits

Chess team for providing and recording through documentation on basic Franka controls.
